D'Orly DC-0502 Piston Compressor – 50L – 240 L/min – Professional

D'Orly
dc-0502

A reliable 50L piston compressor with an air intake capacity of 240 L/min, ideal for professional use in various applications requiring steady and efficient air compression.
Contact
  • Single-Phase Design with Plug: Ready for professional use with easy plug-in setup.
  • Large Pressure Regulator: Allows seamless adjustment to the desired pressure level.
  • Copper-Wound Motor with Thermal Protection: Ensures durability and safety during intensive use.
  • Fully Cast-Iron Compressor Head: Large cylinder capacity and low RPM extend the lifespan.
  • Cast-Iron Belt Pulley: Minimizes slip, maximizing grip and efficiency.
  • Direct Tank Connection: Provides maximum working pressure.
  • Certified, Powder-Coated Tank: Durable finish with certification for reliability.
  • Portable Design: Equipped with wheels and an ergonomic handle for easy mobility.
  • Intake Capacity: 240 L/min
  • Max Pressure: 8 Bar
  • Power: 2 Hp
  • Phase: Single-phase
  • Voltage: 230V
  • Cylinder Head: 1 cylinder
  • RPM: 900 rpm
  • Tank Capacity: 50L
  • Weight: 54 kg
  • Noise Level: 72 dB
  • Dimensions (LxWxH): 850 x 410 x 740 mm

Delivery Contents

  • D’Orly DC-0502 Piston Compressor – 50L – 240 L/min – Professional

LPDORDC0502

D'Orly DC-1004TP Piston Compressor – 100L – 400 L/min – Professional

D'Orly
dc-1004tp

A robust 100L piston compressor with an air intake capacity of 400 L/min, designed for professional applications requiring reliable and efficient air compression.
Contact
  • Three-Phase Design: Built for professional use, operates without a neutral conductor, and is supplied without a plug.
  • Large Pressure Regulator: Allows precise, stepless adjustment to the desired pressure.
  • Copper-Wound Motor with Thermal Protection: Ensures durability and safety under heavy use.
  • Fully Cast-Iron Compressor Head: Large cylinder capacity and low RPM for extended lifespan.
  • Cast-Iron Belt Pulley: Reduces slip, providing more grip and efficiency.
  • Direct Tank Connection: Delivers maximum working pressure.
  • Certified, Powder-Coated Tank: Durable finish with certification for reliability.
  • Portable Design: Equipped with wheels and an ergonomic handle for easy mobility.
  • Intake Capacity: 400 L/min
  • Max Pressure: 8 Bar
  • Power: 4 Hp
  • Phase: Three-phase
  • Voltage: 400V
  • Cylinder Head: 2 cylinders
  • RPM: 800 rpm
  • Tank Capacity: 100L
  • Weight: 73 kg
  • Noise Level: 74 dB
  • Dimensions (LxWxH): 1200 x 470 x 830 mm

LPDORDC1004

D'Orly RH-Series DRH-0503 Piston Compressor – 3 Hp

D'Orly
drh-0503

A 3 Hp piston compressor with a 50L tank capacity, delivering an output of 350 liters per minute, ideal for professional use requiring reliable and efficient air supply.
Contact

A robust 50L piston compressor with an output of 350 liters per minute, specifically assembled for the D’Orly RH-Series with industrial-grade components.

Key Features

  • Premium 2-Cylinder Pump (K17): Ensures reliable performance and durability.
  • Condor Pressure Regulator: Allows precise control of air pressure.
  • Cast-Iron Components: Includes pulley, fan, and other critical parts for enhanced durability.
  • Belt-Driven Design: Operates at low RPM for extended compressor life.
  • Fully Powder-Coated Tank: Provides added protection and a durable finish.
  • Large Aftercooler: Ensures efficient cooling, contributing to a longer lifespan.
  • Capacity: 350 L/min net output
  • Cylinders: 2
  • RPM: 900
  • Power: 3 Hp (2.2 kW)
  • Tank Capacity: 50 L
  • Max Pressure: 10 Bar
  • Dimensions (LxWxH): 850 x 400 x 740 mm
  • Weight: 52 kg
  • Voltage: 230V
  • Noise Level: 72 dB
  • Head Type: K17

LPDORDRH0503

D'Orly RH-Series DRH-0503 Piston Compressor – 50L – 350 L/min – Professional

D'Orly
drh-0503

A professional-grade piston compressor with a 50L tank and a net output of 350 L/min, ideal for demanding applications. Featuring a durable 2-cylinder K17 pump, this compressor operates at 900 RPM for extended lifespan and efficient performance.

Contact
  • Single-Phase Design with Plug: Ready for professional use with easy plug-in setup.
  • Cast-Iron Belt Pulley: Reduces slip and enhances grip for reliable operation.
  • High-Quality K-Series Compressor Head: Large cylinder capacity with in-line cylinder formation for smooth, quiet operation. Equipped with a large flywheel for optimal cooling.
  • Copper-Wound Motor with Thermal Protection: Ensures safe, durable performance under intensive use.
  • Stable Wheels: Full, sturdy wheels provide stability during operation.
  • Certified Powder-Coated Tank: Durable, certified finish for extended lifespan.
  • Condor Pressure Switch (Made in Germany): Reliable operation with high-quality German engineering.
  • Professional Pressure Regulator with Water Separator: Delivers clean, dry air for optimal performance.
  • Folding Handle: Compact storage and easy, ergonomic transport.
  • Includes Mounted Tank Drain Hose: For convenient and efficient maintenance.
  • Intake Capacity: 350 L/min
  • Max Pressure: 10 Bar
  • Power: 3 Hp
  • Phase: Single-phase
  • Voltage: 230V
  • Cylinder Head: 2-cylinder K17
  • RPM: 900
  • Tank Capacity: 50L
  • Weight: 52 kg
  • Noise Level: 72 dB
  • Dimensions (LxWxH): 850 x 410 x 740 mm

Delivery Contents

  • D’Orly RH-Series DRH-0503 Piston Compressor – 50L – 350 L/min – Professional


LPDORDRH0503

D'Orly RH-Series DRH-1004 Piston Compressor 400V – 100L – 450 L/min – Professional

D'Orly
drh-1004

A professional-grade 100L piston compressor with an air intake capacity of 450 L/min, designed for intensive applications requiring reliable, three-phase power at 400V. Ideal for workshops and industrial use.

Contact
  • Three-Phase Design for Professional Use: Operates without a neutral conductor and is supplied without a plug.
  • Cast-Iron Belt Pulley: Reduces slip, providing enhanced grip and reliable operation.
  • High-Quality K-Series Compressor Head: Large cylinder capacity with an in-line cylinder formation for smooth, quiet operation, complemented by a large flywheel for optimal cooling.
  • Copper-Wound Motor with Thermal Protection: Ensures safe, durable performance under heavy use.
  • Stable Wheels: Full, robust wheels provide optimal stability during operation.
  • Certified, Powder-Coated Tank: Durable finish with certification for reliability.
  • Condor Pressure Switch (Made in Germany): High-quality German engineering for dependable operation.
  • Professional Pressure Regulator with Water Separator: Ensures clean, dry air for enhanced performance.
  • Folding Handle: Compact storage and ergonomic transport.
  • Includes Mounted Tank Drain Hose: For convenient and efficient maintenance.
  • Intake Capacity: 450 L/min
  • Max Pressure: 10 Bar
  • Power: 4 Hp
  • Phase: Three-phase
  • Voltage: 400V
  • Cylinder Head: 2-cylinder K18
  • RPM: 900
  • Tank Capacity: 100L
  • Weight: 69 kg
  • Noise Level: 74 dB
  • Dimensions (LxWxH): 1200 x 470 x 830 mm

Delivery Contents

  • D’Orly RH-Series DRH-1004 Piston Compressor – 100L – 450 L/min – Professional

LPDORDRH1004

D'Orly RH-Series DRH-2705 Piston Compressor – 270L – 650 L/min – Industrial

D'Orly
drh-2705

An industrial-grade 270L piston compressor with an intake capacity of 650 L/min, designed for demanding applications where high air output and reliable performance are essential. Ideal for continuous use in workshops and industrial environments.

Contact
  • Three-Phase Design for Demanding Use: Built for industrial applications, operates without a neutral conductor, and supplied without a plug.
  • Cast-Iron Belt Pulley: Reduces slip and enhances grip for reliable performance.
  • High-Quality K-Series Compressor Head: Large cylinder capacity with in-line cylinder arrangement for smooth, quiet operation; equipped with a large flywheel for optimal cooling.
  • Copper-Wound Motor with Thermal Protection: Ensures safe and durable operation under intensive use.
  • Stable, Heavy-Duty Wheels: Provides optimal stability, even on uneven surfaces.
  • Certified, Powder-Coated Tank: Durable, certified construction with a robust finish.
  • Condor Pressure Switch (Made in Germany): High-quality engineering for dependable operation.
  • Professional Pressure Regulator with Water Separator: Provides clean, dry air for enhanced tool and equipment performance.
  • Folding Handle: For compact storage and ergonomic handling.
  • Rotatable Table for Belt Adjustment: Allows easy belt tensioning with just one wrench.
  • Includes Mounted Tank Drain Hose: Facilitates convenient and efficient maintenance.
  • Intake Capacity: 650 L/min
  • Max Pressure: 11 Bar
  • Power: 5.5 Hp
  • Phase: Three-phase
  • Voltage: 230/400V
  • Cylinder Head: 2-stage K28
  • RPM: 900
  • Tank Capacity: 270L
  • Weight: 140 kg
  • Noise Level: 76 dB
  • Dimensions (LxWxH): 1550 x 530 x 1070 mm

Delivery Contents

  • D’Orly RH-Series DRH-2705 Piston Compressor – 270L – 650 L/min – Industrial

LPDORDRH2705

D'Orly RH-Series Automatic Condensate Drain 380V 1/4″

D'Orly RH-Series Automatic Condensate Drain 380V 1/4″

An automatic condensate drain from the D'Orly RH-Series, designed for efficient moisture removal in compressed air systems. Operates at 380V with a 1/4″ connection, ideal for industrial applications requiring reliable and consistent drainage.

  • Metal Nozzle with Plastic Handle: Combines durability with lightweight handling.
  • Equipped with Orion Plug: Ensures compatibility with standard air systems.
  • 110mm Nozzle Length: Ideal for precise cleaning and dust removal.
  • Ergonomic Design: Provides comfort during extended use in industrial and workshop settings.
  • Pressure Range: 0-16 bar
  • Voltage Options: 12-380 VAC/DC, 50/60 Hz
  • Medium Temperature: 1-55 ℃
  • Ambient Temperature: 1-55 ℃
  • Timer Cycle (ON/OFF): 0.5-10 seconds / 0.5-45 minutes
  • Timer PCB Technology: SMD
  • Timer Cycle Indicator: LED
  • Valve Type: 2/2 way, direct acting
  • Valve Orifice: 4.5 mm
  • Valve Seal Material: FPM
  • Inlet/Outlet Connection: 1/8″, 1/4″, 3/8″, 1/2″ (BSP or NPT)
  • Inlet Height: 1 cm

LPRED30005

D'Orly RH-Series Automatic Condensate Drain 230V 1/4″

D'Orly RH-Series Automatic Condensate Drain 230V 1/4″

An automatic condensate drain designed for efficient moisture removal in compressed air systems, operating at 230V with a 1/4″ connection. Ideal for industrial applications requiring reliable and consistent drainage.

  • Compatible Model: Specifically designed for the RedHead 50/350 Piston Compressor 230V 3Hp.
  • Unlimited Compressor Capacity: Suitable for a wide range of compressor capacities.
  • Durable Valve Construction: Made from high-quality brass and stainless steel for extended reliability.
  • Test Function and Maintenance Capability: Includes a built-in test function and easy maintenance access for optimal performance.
  • Pressure Range: 0-16 bar
  • Voltage Options: 12-230 VAC/DC, 50/60 Hz
  • Medium Temperature: 1-55 ℃
  • Ambient Temperature: 1-55 ℃
  • Timer Cycle (ON/OFF): 0.5-10 seconds / 0.5-45 minutes
  • Timer PCB Technology: SMD
  • Timer Cycle Indicator: LED
  • Valve Type: 2/2 way, direct acting
  • Valve Orifice: 4.5 mm
  • Valve Seal Material: FPM
  • Inlet/Outlet Connection: 1/8″, 1/4″, 3/8″, 1/2″ (BSP or NPT)
  • Inlet Height: 1 cm

Delivery Contents

  • D’Orly RH-Series Automatic Condensate Drain 230V 1/4″

LPRED30003

D'Orly RH-Series Air Blow Gun Metal – Orion Plug – 110mm

D'Orly RH-Series Air Blow Gun Metal – Orion Plug – 110mm

A durable metal air blow gun from the D'Orly RH-Series, equipped with an Orion plug and a 110mm nozzle, ideal for precise cleaning and dust removal in various industrial and workshop settings.

  • Metal Nozzle with Plastic Handle: Combines durability with lightweight handling.
  • Equipped with Orion Plug: Ensures compatibility with standard air systems.
  • 110mm Nozzle Length: Ideal for precise cleaning and dust removal.
  • Ergonomic Design: Provides comfort during extended use in industrial and workshop settings.

Technical Specifications of D’Orly RH-Series Air Blow Gun Metal – Orion Plug – 110mm

  • Gun Material: Plastic
  • Nozzle Material: Metal
  • Nozzle Length: 110 mm
  • Air Consumption: 380 L/min
  • Connection Type: Orion plug

Delivery Contents

  • D’Orly RH-Series Air Blow Gun Metal – Orion Plug – 110mm

LPRED27102MT6A

D'Orly RH-Series Air Blow Gun Metal – Euro Plug – 110mm

D'Orly RH-Series Air Blow Gun Metal – Euro Plug – 110mm

A sturdy metal air blow gun from the D'Orly RH-Series, fitted with a Euro plug and a 110mm nozzle, perfect for precision cleaning and dust removal in industrial and workshop environments.

  • Metal Nozzle with Plastic Handle: Combines durability with lightweight handling.
  • Equipped with Euro Plug: Ensures compatibility with standard European air systems.
  • 110mm Nozzle Length: Ideal for precise cleaning and dust removal.
  • Ergonomic Design: Provides comfort and control during extended use in industrial and workshop settings.
  • Gun Material: Plastic
  • Nozzle Material: Metal
  • Nozzle Length: 110 mm
  • Air Consumption: 380 L/min
  • Connection Type: Euro plug

Delivery Contents

  • D’Orly RH-Series Air Blow Gun Metal – Euro Plug – 110mm

LPRED27102MT7E
